Name: CZI TD40 Drone Delivery System
Brand: CZI
SKU: CZI-TD40
Price: 749.0 USD
Availability: InStock

CZI TD40 Drone Delivery System

$749.00

The CZI TD40 is a precision payload delivery system built for the DJI Agras T40 and T20P agricultural drones. Designed for operations that require controlled release of materials from altitude, the TD40 integrates directly with the T40's PSDK payload bay for single-pilot release control through the standard DJI controller. It provides reliable, repeatable precision drops for field operations requiring aerial material deployment.

The TD40 features a durable, lightweight construction optimized for the T40 and T20P airframes, with a quick-release mechanism that enables fast field installation and removal. Operator control of the release is handled through the drone's existing software interface, with real-time status monitoring to confirm payload state before and after release.

Please note: The CZI TD40 is compatible exclusively with the DJI Agras T40 and T20P agricultural sprayer drones. It is not compatible with DJI enterprise inspection platforms such as the Matrice 30, Matrice 350 RTK, or Mavic 3 Enterprise series. If you need a drop system for a Matrice or Mavic platform, please see our JZ drop system collection.

Compatible drones: DJI Agras T40, DJI Agras T20P
Integration: PSDK payload bay
Control: single-pilot release via DJI controller
Mount: quick-release installation and removal

Free Delivery

Free delivery and returns

Warranty

1-Year warranty policy

Quantity

Product Highlights
User Manual
Product Specs

CZI TD40 Product Highlights

Payload Capacity

TD40 supports up to 40 kg total payload across 4 hooks; TD40P doubles capacity to 80 kg with 8 hooks, each rated for 10 kg.

Delivery Configuration

Supports both single-drop and programmable multi-drop operations; independent release hooks allow sequential or simultaneous payload deployment.

Mounting & Installation

Features a quick-release hinge system for fast, tool-free installation; enables rapid mission readiness and simplified field maintenance.

Scalability

Allows dual-system parallel mounting for expanded payload delivery, doubling operational capacity within a single flight mission.

Precision & Reliability

Built with high-torque servo release mechanisms ensuring accurate and controlled air-to-ground payload drops under variable flight conditions.

Build & Safety

Industrial-grade aluminum alloy frame with reinforced joints; engineered for vibration resistance, overload protection, and long-term durability.

Integration & Control

Seamlessly integrates with enterprise UAV platforms via dedicated control interface; supports remote release activation and mission sequencing.

Ideal Applications

Public safety, law enforcement, search & rescue, industrial inspection, maritime illumination, and utility maintenance.

CZI TD40 User Manual

Product Specs

Dimensions
Maximum height: 186 mm (excluding antenna)
Maximum length: 415 mm

Weight
Sky end: 0.8 kg (TD40) / 1.6 kg (TD40P)
Ground end: 60 g

Function
Capable of mounting 4 (TD40) or 8 (TD40P) payload hooks for single or sequential automatic aerial delivery.
Each hook supports up to 10 kg, with total payload capacity of 40 kg (TD40) or 80 kg (TD40P).
Supports the parallel use of two systems for extended payload delivery.
Quick and easy tool-free installation and removal.

Working Temperature
-15 °C to +40 °C

Mounting Interface
Quick-release hinge system for secure installation and fixation.

Control Mode
External expansion remote controller integrated with DJI T40 and T20P drones.

Control Distance
Up to 2 kilometers

FIND YOUR ANSWERS HERE

FREQUENTLY ASKED QUESTIONS

What is the CZI TD40/TD40P Drone Delivery System?

The TD40/TD40P is a modular aerial delivery system that enables drones to carry and release payloads of up to 40 kg or 80 kg with precision and reliability.

What is the difference between the TD40 and TD40P models?

The TD40 supports up to 40 kg across four hooks, while the TD40P offers double the capacity—80 kg and eight hooks—for larger or more complex delivery missions.

Which drones are compatible with the TD40/TD40P system?

The TD40/TD40P is designed for integration with enterprise-grade UAV platforms that support high-payload accessories, including many CZI and DJI enterprise drones.

How does the multi-drop feature work?

Each release hook operates independently, allowing users to program sequential or simultaneous drops for efficient delivery across multiple locations.

Can two TD40/TD40P systems be used together?

Yes, two units can be mounted in parallel to expand payload and delivery capacity in a single flight operation.

What applications is this system best suited for?

The TD40/TD40P is ideal for emergency supply delivery, disaster response, firefighting, defense logistics, and agricultural support missions.
