CZI LP20

$2,199.00

The CZI LP20 is a compact, multi-function broadcasting and searchlight payload designed exclusively for the DJI Matrice 3D and 3TD series. Combining a 120 dB loudspeaker, high-intensity LED searchlight, and integrated flashing lights, the LP20 empowers drone operators with enhanced aerial communication and low-light performance. With an effective broadcasting range of 300 m, a searchlight beam angle of 13.5°, and illumination reaching 32 lux at 50 m, this four-in-one payload delivers crystal-clear voice projection and powerful illumination for search & rescue, emergency response, public safety, and crowd management missions.

Weighing just 200 g, the LP20 seamlessly integrates with DJI Pilot 2, FlightHub 2, and CZI Assistant, offering real-time AI capabilities like sound pickup feedback, automatic spot tracking, and AI-based light centering. Built to perform in tough conditions, the LP20 is IP53-rated for dust and water resistance and operates reliably between –20 °C to 50 °C. Whether deployed for tactical response or broadcast operations, the LP20 delivers unmatched efficiency, clarity, and situational awareness from takeoff to landing.

Quantity
  • Product Highlights

  • User Manual

  • Product Specs

Four-in-One Payload

Combines a searchlight, loudspeaker, flashing lights, and microphone in one compact module.

High-Volume Output

Up to 120 dB @ 1 m, projecting audio clearly up to 300 m.

Powerful Searchlight

13.5° FOV beam, 32 lux @ 50 m, providing focused long-range illumination.

Multiple Light Modes

Red/Blue, Blue/Blue, Red/Red, and Yellow/Yellow strobe configurations for visibility and signaling.

Smart AI Functions

Sound pickup feedback, automatic light centering, and AI spot following for intelligent control.

Seamless DJI Integration

Fully compatible with DJI Pilot 2, FlightHub 2, and CZI Assistant software.

Rugged & Lightweight

Only 200 ± 5 g; rated IP53, operates from –20 °C to 50 °C for field durability.

Model
LP20

Dimensions
127 × 147 × 78 mm

Weight
200 ± 5 g

Protection Grade
IP53

Operating Temperature
-20°C to 50°C

Total Power
<50 W

Sound Pressure
120 dB @ 1 m (2.1 kHz)

Effective Broadcasting Distance

300 m

Searchlight Field of View
13°

Central Illuminance
32 lux @ 50 m
14 lux @ 75 m
8 lux @ 100 m

Software Support
FlightHub 2
Pilot 2
CZI Assistant

Broadcasting Modes

Recording broadcasting

Multi-language TTS

File playback

Flashing Light Modes

Red and blue flashing

Blue and blue flashing

Red and red flashing

Yellow and yellow flashing

Additional Functions

Sound pickup feedback

Spot following

AI centering

FIND YOUR ANSWERS HERE

FREQUENTLY ASKED QUESTIONS

Which drones are compatible with the CZI LP20?

The LP20 is designed for the DJI Matrice 3D and 3TD drones, including DJI Dock 2 operations.

How loud is the LP20 speaker?

The LP20 delivers up to 120 dB @ 1 m, with an effective broadcast range of approximately 300 meters, ideal for public safety and search & rescue.

What is the illumination range of the searchlight?

The searchlight has a 13.5° beam angle, providing 32 lux @ 50 m, 14 lux @ 75 m, and 8 lux @ 100 m illumination.

Does the LP20 include flashing lights?

Yes. It includes multi-color flashing modes (red/blue, blue/blue, red/red, yellow/yellow) for signaling and night visibility.

What software is supported?

The LP20 integrates seamlessly with DJI Pilot 2, DJI FlightHub 2, and CZI Assistant, allowing real-time control of audio and lighting functions.

Is the LP20 weather-resistant?

Yes. It has an IP53 rating, offering dust and water resistance, and operates in temperatures from –20 °C to 50 °C.

Can it play pre-recorded messages or text-to-speech?

Yes. The LP20 supports real-time audio broadcasting, recorded playback, and multi-language text-to-speech (TTS) capabilities.
